Electric Outboard Motor Epropulsion Spirit 1.0 Evo Tiller 3HP 1kW

Spirit 1.0 Evo is a portable 3HP electric outboard made for dinghies, fishing boats, and sailboats. It features a 1276Wh large integrated lithium battery for long range. The hydrogeneration function is great for sustainable sailing experience. The safety wristband keeps you safe in case of MOB.

Hydrogeneration

Spirit 1.0 Evo is the first-ever electric outboard that features hydrogeneration. ePropulsion pioneers in the innovation of electric outboard motors and we dedicate ourselves to sustainable sailing.

The hydrogeneration data is based on real tests with the anti-ventilation plate installed.

Specifications

	Spirit 1.0 Evo	Spirit 1.0 Evo Remote
Power	1 kW (3HP equivalent)	1 kW (3HP equivalent)
Standard Battery	Spirit Battery Plus, 1276 Wh li-ion polymer	Spirit Battery Plus, 1276 Wh li-ion polymer
Input Voltage	39V – 60V	39V – 60V
Motor Weight*	11.3 kg / 24.9 lbs	10.6 kg / 23.4 lbs
Battery Weight	8.7 kg / 19.2 lbs	8.7 kg / 19.2 lbs
Standard Charging	8.5 Hrs	8.5 Hrs
Fast Charging	3.5 Hrs	3.5 Hrs
External Battery	Yes, and E-Series Battery recommended	Yes, and E-Series Battery recommended
Propeller	11″ × 5.8″ 2-blade composite propeller	11″ × 5.8″ 2-blade composite propeller
Trim / Tilt Angle	0°, 7°, 14°, 21° / 85°	0°, 7°, 14°, 21° / 85°
Shaft Length	Short, Long	Short, Long
Control	Evo Tiller	Evo Top Mount Control / Evo Side Mount Control / Evo Dual Remote Control
Hydrogeneration	Yes	Yes
Motor	Brushless DC motor	Brushless DC motor
Direct Drive	Yes	Yes
Maintenance-Free	Yes	Yes

*The weight is measured with the short shaft version.

Performance

At the core of Spirit 1.0 Evo electric outboard motor, it’s a 1kW BLDC motor, equivalent to 3HP.

Power (W)	Speed (mph / kph)	Runtime (hh:mm)	Range (mile / km)
35	2.2 / 3.5	36:25	80 / 129
65	2.7 / 4.3	19:35	53 / 85.3
125	3.5 / 5.6	10:00	35 / 56
250	4.4 / 7.1	5:00	22 / 35.5
500	5.3 / 8.5	2:30	13.3 / 21.3
750	5.7 / 9.2	1:40	9.5 / 15.3
1000	6.2 / 10	1:15	7.8 / 12.5

*The performance data is based on a 12-foot aluminum boat with one person and one Spirit battery Plus in calm lake water. The actual speed, range and running time may vary because of different boats, load, weather, etc.

With one charge, you can go 22 miles at 4.5 mph, or go fishing all day long at trolling speed.

Battery

The integrated rechargeable battery is lightweight, only 19 lbs or 8.7 kg, and robust for tough conditions.

Positive Buoyancy

Never worry the battery drops into the water.

1276Wh Capacity

High energy density in a compact size to build large battery capacity.

180W Solar Charging

Dual power ports allow solar charging when discharging.

E-Series Battery

Extend the runtime to an entire day by replacing the integrated Spirit battery.

Designed for Portability

Spirit 1.0 Evo outboard with battery is portable & easy to transport. It would be a pleasure to have Spirit 1.0 Evo in your gear list when preparing a trip.
